BEARING UCS205-015 15/16''

The UCS205-015 Ball Insert Bearing is a high-quality, standard-duty bearing designed for smooth, efficient performance in a wide range of industrial applications. With a 15/16" cylindrical bore and a set screw locking mechanism, it provides secure shaft attachment and reliable operation even under demanding conditions.

Built from through-hardened steel for superior strength and wear resistance, this bearing delivers excellent load-carrying capability and long service life. The contact seal ensures effective protection against contaminants, while the sealed closure type helps retain lubrication for low-maintenance performance.

Operating within a wide temperature range of -40°F to 250°F, the UCS205-015 is ideal for standard-duty applications requiring precision, durability, and consistent performance.

Specifications

• Bore Diameter: 15/16"

• Outside Diameter: 2.0472"

• Overall Width: 1.3386"

• Locking Device: Set Screw

• Bearing Material: Through-Hardened Steel

• Seal Type: Contact, Sealed

• Dynamic Load Capacity: 3150 lbf

• Static Load Capacity: 1760 lbf

• Operating Temperature: -40°F to 250°F

• Finish: Uncoated

• Weight: 0.463 lbs

Applications
Suitable for use in agricultural machinery, conveyors, light industrial equipment, and other applications requiring a dependable and easily installed mounted bearing insert.
