LOCTITE 609 RETAINER MEDIUM 50ML

M-609

$42.67

Secure cylindrical assemblies with precision and strength using Loctite® 609, a green, high-strength methacrylate-based retaining compound formulated for the bonding of cylindrical fitting parts. Designed to augment press and slip fits, Loctite 609 cures anaerobically (in the absence of air) between close-fitting metal surfaces to create a reliable, vibration-resistant bond that prevents loosening and leakage.

With its low viscosity (120 mPa·s) and excellent capillary action, Loctite 609 flows easily into tight clearances, forming a strong, permanent connection between components such as rotors and shafts, bushings, sleeves, and bearings. Once cured, it delivers a shear strength of 15.8 N/mm² and resists temperatures from –55°C to +150°C, ensuring lasting performance in high-stress, high-speed environments.

Proven through testing under Military Specification Mil-R-46082B, Loctite 609 provides trusted reliability for motors, pumps, gearboxes, and precision mechanical assemblies where maintaining tight tolerances and alignment is critical.

Key Features:

High-strength retaining compound for cylindrical metal assemblies
Augments press and slip fits to prevent movement, loosening, and leakage
Low viscosity (120 mPa·s) allows penetration into tight clearances
Prevents vibration-induced loosening and increases load transmission
Shear strength: 15.8 N/mm²
Cures anaerobically between close-fitting metal surfaces
Temperature resistant from –55°C to +150°C
Tested to Military Specification Mil-R-46082B (regional approval)
Colour: Green
Ideal for rotor-to-shaft bonding, bushings, sleeves, and bearing retention

Specifications:

Brand: Loctite®
Model: 609
Type: Retaining Compound
Colour: Green
Size: 50 mL
Viscosity: 120 mPa·s (Low)
Strength: High
Shear Strength: 15.8 N/mm²
Cure Time: 24 hours
Temperature Range: –55°C to +150°C

Strong, precise, and dependable — Loctite® 609 is the go-to choice for securing cylindrical assemblies with high accuracy and lasting performance.
